Climate control emblem measurement

[adri4n]

Hi Everyone, I am a new EK9 owner in Australia, been reading lots on the forum and have recently acquired my very own RX model.

Unfortunately I am missing an emblem on the front climate control and cant seem to find a replacement. I am going to look into 3d printing but I would like some measurements if someone can do some for me that would be great, would need width and height and any other measurements would be great. Picture the emblem in question. Thanks



[Bart83]

Hello,

Also new to the forum, working on creating a EK9 replica (LHD). Did some work on the HVAC panel and Type R badge. I can share the .stl with you.
Not having acces to an actual EK9 I was not able to take measurements from the real badge. Used the panel dimenstions as reference, think i got it close to the oem badge. Happy with the 3d printed result, letters are painted using humbrol enamel, still gor the chrome ''civic'' to do, plan on using chrome nail polish for this.

Kind regards,

Bart



[adri4n]

Wow that looks great, would love the .stl if thats ok. I have managed to get some measurements from a friend I met while buying the EK9. He kindly took some time to measure it out

Oh if its even possible to somehow pay you to print and post this to Australia please let me know. Thanks



[Bart83]

Hey thanks for that pictures! I got it pritty close based on the pictures i found on the web. Awnsered your pm just now . . .

Kind regards,

Bart



[Bart83]

Dimensions from the cad model



[k.osamu]

Dimensions from the cad model

View attachment 51971

Hello,
I’m an EK owner from Taiwan, currently restoring my 2000 Civic EK (Taiwan domestic model).
I’m trying to make it look like the EK9, and I was wondering if you could share your STL file with me.
It would really help me a lot!
Sincerely waiting for your reply, and thank you very much.



[Bart83]

Yes, sent me a PM with your email and I will share the file with you



[NomTimes3]

@Bart83, could you please share the file with me as well?

Also, if you’re in the US and need to take measurements I’m more than happy to meet up with you if you’re close once the car is out of the shop. Or send you pictures if you’re not.



[Bennp_builds]

Hello,

Also new to the forum, working on creating a EK9 replica (LHD). Did some work on the HVAC panel and Type R badge. I can share the .stl with you.
Not having acces to an actual EK9 I was not able to take measurements from the real badge. Used the panel dimenstions as reference, think i got it close to the oem badge. Happy with the 3d printed result, letters are painted using humbrol enamel, still gor the chrome ''civic'' to do, plan on using chrome nail polish for this.

Kind regards,

Bart

Hey Bart, I’m trying to build my ej9 to resemble an ek9, I would really appreciate copies of the files you got for my build, would you happen to have measurements or stl of the whole climate control panel or just the badge? Either helps thanks man!
