JDM Quartet. Y56 EK9, B18C EG6 SiR2, K20 96 DC2, Red 96 DC2

Samuel Kidney

Member
Joined
Dec 17, 2016
Messages
23
Car(s)
Phoenix Yellow EK9 - 1996 DC2 Type R - EG6 SiR2
Great to meet you earlier Sam, its a small world!
Looking forward to seeing the EK9 progress
You too mate. It is indeed!
Fingers crossed it'll not be too much longer before I can start getting somewhere with it.


JohnTurbo

Well-Known Member
Joined
Oct 3, 2013
Messages
941
If you find you don't get a chance - I know of a nice silver shed that could be reshelled ;-)


Samuel Kidney

Member
Joined
Dec 17, 2016
Messages
23
Car(s)
Phoenix Yellow EK9 - 1996 DC2 Type R - EG6 SiR2
EG6 still away at the body shop, hopes of taking it to Cadwell next month are slipping away with each day but I suppose as long as the final result is good thats all that matters!

Received some goodies in the past week:

New set of Enkei RPF1s in 16x8 ET38 courtesy of Mr Ivell at 6two1.
Wiseco pistons in 12.5:1 0.5 oversized. Received the block back from the machinist along with the pistons this morning following a re-bore to suit. They've also set the piston to wall clearance for me so that's one less thing to worry about when it's assembled.



I'm just waiting on the delivery of my new cams and valve springs (BC Stage 3 and appropriate springs/ti retainers) and valves prior to assembly.


The white DC2 also saw some love recently too!
Renewed oil and filter, rear brake pads, brake fluid flush, new A048s and a replacement exhaust all sorted before a last minute trip out to Oulton park on the 27th. The car performed impeccably, definitely humoured my skills after a year and a bit away from some fast driving.



Hoping its only a couple of weeks before the EG6 can be buttoned up and booked in for mapping, at which point my focus can turn to getting the red DC2 stripped down and ready to be sent away for paint.


JohnTurbo

Well-Known Member
Joined
Oct 3, 2013
Messages
941
Nice!

Either my EJ or my kitcar have a trackday booked for 12th July at Croft. My first in a couple of years!


Samuel Kidney

Member
Joined
Dec 17, 2016
Messages
23
Car(s)
Phoenix Yellow EK9 - 1996 DC2 Type R - EG6 SiR2
Sourced some oem 96 wheels for the red dc2. Couldn’t resist popping them on and giving it a quick spray down while I was de-greasing the bay this evening. It looks a million times better just for being off the horrid gold wheels.



Samuel Kidney

Member
Joined
Dec 17, 2016
Messages
23
Car(s)
Phoenix Yellow EK9 - 1996 DC2 Type R - EG6 SiR2
Another outing! Nearly two years since we’ve been back to Cadwell. Had a mad rush getting these three ready for the day, all performed superbly.








DC2 is phenomenal at the minute. With an eyeballed alignment it managed a 1:41.8 in the afternoon. I say “it” because it definitely humours my driving
:lol:


Samuel Kidney

Member
Joined
Dec 17, 2016
Messages
23
Car(s)
Phoenix Yellow EK9 - 1996 DC2 Type R - EG6 SiR2
Despite my best efforts to do so, I missed the opportunity to take the EG6 to Mimms on sunday with a misfire just creeping in at 11;45pm Saturday night to dash my hopes.

That said, we did only collect the car on Wednesday from paint and got this far with it by Saturday evening, so I'll take it as a fair achievement!

Collected the car Wednesday last week:

EG6 12.jpg


Straight into the workshop on return.
We'd already prepped the B18C with a new timing belt, water pump, tensioner and oil/filter before hand.



Followed by all the necessary brake lines, brake servo, cylinder (clutch and brake) and bias valve.
Fuel filter bracket and lines on too.

Brakes test fitted, all good.

EG6 4.jpg


Refurbished cam cover fitted, along with an ITR DC2 airbox and intake tube.
Then it was panels/body associated parts.

EG6 8.jpg

EG6 6.jpg


I think the back end of an EG is the best part of them, such an iconic look!

EG6 10.jpg


Interior comprises of the original SiR2 purple tweed fold flat rear interior with DC2 SR3 Recaros up front.
Personal Neo Grinta steering wheel, Spoon delrin gear knob and SIR clocks.

EG6 7.jpg


Quite an effort, but fingers crossed this evening should be the first proper drive now its misfire has been fixed. (And the weather permits!)

A fairly simple spec, it should still provide lots of pleasure to drive and remain reliable.

Quick run down on spec:

1994 Civic EG6 SiR-2 painted in Y56 Phoenix Yellow
Bronze glass all round
Purple Tweed Interior (Fold flat)
Red Recaro SR3 seats up front

Engine/gearbox:
1996 JDM B18C
4.4 S80 LSD
5Zigen 4-2-1 Exhaust manifold
Kakimoto cat back exhaust 2.5"
DC2 shifter linkage/dual bend shifter
Fuelling cared for by a new Walbro 255 pump

Suspension:
Yellowspeed Premium Competition Coilovers
Hardrace rear toe arms
Hardrace rear camber arms
Polybushed OEM rear LCA's
DC2 front anti-roll bar
DC2 rear anti-roll bar
Polybushed throughout

Braking:
Wilwood 4 Piston calliper
Wilwood 318mm disc
Freakyparts disc bell
Freakyparts calliper adaptor
Ferrodo DS3000 front pads
OEM 242 rears
Pagid OEM pads
PBS brake fluid


Samuel Kidney

Member
Joined
Dec 17, 2016
Messages
23
Car(s)
Phoenix Yellow EK9 - 1996 DC2 Type R - EG6 SiR2
Well.. excitement short lived with the EG6 with lots of faults finding their way through the paint after just 5 weeks. Gutted is an understatement. Rust appearing on the N/S/R arch, moisture coming through on the quarters and bubbling/rust/crazing appearing everywhere. Going back in soon to be re-done with another shop pending a refund from the bloke that did it.

Gutted in honesty, but life goes on. Here’s a few shots from the track day/workshop over the last month.





Samuel Kidney

Member
Joined
Dec 17, 2016
Messages
23
Car(s)
Phoenix Yellow EK9 - 1996 DC2 Type R - EG6 SiR2
The EK9 shell has sold.
I'm hoping to buy a complete example next year all being well, I just cant commit the time and expense that the Yellow shell needed.

I have now ordered the following for the EG6s built B18C which means its edging ever closer to completion:
- Brian Crower BC0013 Stage 3 N/A spec camshafts
- Brian Crower BC0010s valve springs and steel retainers.

I opted for steel retainers for longevity between inspections. It's been noted by a few that titanium retainers should be subject to inspection and/or replacement every so often. Deemed a consumable in a race engine apparently and my wallet doesnt like the sound of that!

Supertech flatface valves, ACL conrod/main/thrust bearings and ferrea valve guides to sort next and thats just about everything needed to start initial assembly to check P2V and V2V clearances before final assembly and cam timing/degree.


B18C'R EK

Donator
Donator
Joined
Jul 8, 2010
Messages
3,718
The EK9 shell has sold.
I'm hoping to buy a complete example next year all being well, I just cant commit the time and expense that the Yellow shell needed.

I have now ordered the following for the EG6s built B18C which means its edging ever closer to completion:
- Brian Crower BC0013 Stage 3 N/A spec camshafts
- Brian Crower BC0010s valve springs and steel retainers.

I opted for steel retainers for longevity between inspections. It's been noted by a few that titanium retainers should be subject to inspection and/or replacement every so often. Deemed a consumable in a race engine apparently and my wallet doesnt like the sound of that!

Supertech flatface valves, ACL conrod/main/thrust bearings and ferrea valve guides to sort next and thats just about everything needed to start initial assembly to check P2V and V2V clearances before final assembly and cam timing/degree.

we can get a another shell sorted when times right ;)

be nice to see the engine done an in the eg :)
